Luce Solar 3 – Next Gen Solar Lighting
Easy to install, low maintenance and highly efficient solar street light incorporating Lithium Ion battery system. The LTC Solar Luce 3 light features and all in one, low profile design with built in motion sensor.
The LTC Luce Solar 3 is an easy to install All-in-one solar light featuring a unique bi-facial solar panel design with larger light collecting area. The Luce Solar 3 incorporates a highly efficient MPPT controller and Lithium Ion battery system.
The Luce Solar 3's maintenance-friendly modular design makes it easier to replace battery and controller. It also includes a LCD battery level Indicator to make regularly monitoring of the battery health simple and fast.
Product details
- Motion detection
- Daylight sensing
- No mains power required
- Zero energy cost
- Long operating hours
- Lithium Ion battery system
- IP66 Weatherproof
Applications
- Street Lighting
- Park Lighting
- Roadway Lighting
- Fence Lighting
- Pathway Lighting
- Campus Lighting
- Ramp Lighting
- Pedestrian Lighting
- Remote Area Lighting
- Private Road Lighting
- Farm & Ranch Lighting
Accessories
- SS304 screws & flexible metal conduit (included)
- Optional Bird Spike available
Specifications
LTC Luce Solar 3 lighting is 4000K CCT with optional 3000K, 5000K and 6000K CCT also available.
| Light Unit | Luce Solar 3.1 | Luce Solar 3.2 |
|---|---|---|
| Item code | 112233 | 112234 |
| Luminaire power rating | 36.86W | |
| Light output | 7070Lm* | |
| Luminaire efficiency | 191.81Lm/W | |
| CCT | 4000K (3000K, 5000K & 6000K optional) | |
| CRI | 80 | |
| Light distribution | Type II (Type III available) | |
| DGIPmax (Maximum Discomfort Glare Index) | 26501 cd/m | |
| LED Lifespan | >50,000 Hours | |
| Housing material | Aluminium | |
| Housing finish | Black, RAL9011 | |
| IP Rating | IP66 | |
| Solar panel type | Bifacial Monocrystalline solar panel | |
| Solar panel rating | 18V, 75W | |
| Solar controller type | MPPT | |
| Battery type | Lithium-ion | |
| Battery voltage | 22.2V | |
| Battery rating (AH) | 30AH | |
| Battery rating (WH) | Approx. 667 WH | 1 KWH |
| Battery level indicator | LCD level indicator included | |
| Motion sensor type | Microwave | |
| Spigot size | 60mm | |
| Light unit orientation | Tiltable (up to 60º) | |
*Tested by NATA accredited lab with 6000K CCT LEDs
Dimensions
Detailed dimension drawings, spacing and polar diagrams are available from our team. Get in touch to discuss with our lighting experts.
Measurements and illustrations are approximate, do not scale.
| Luce Solar 3.1 | Luce Solar 3.2 | |
|---|---|---|
| Dimensions (mm) | 1060 x 380 | 1060 x 380 |
| Weight | 23kg | 27kg |
How it works
When the sun goes down the light turns on. Operation mode can be customised to your requirements.
First 5 hours
When motion is detected, brightness increases to 100%.
After 30 seconds without motion, brightness reduces to 50%.
hours 6-10
When motion is detected, brightness increases to 70%.
After 30 seconds without motion, brightness reduces to 30%.
Hours 11-12
When motion is detected, brightness increases to 100%.
After 30 seconds without motion, brightness reduces to 50%.
