Stealth Flood 1 – G1 Series
Highly efficient flood lights with unique asymmetric light distribution
Highly efficient flood lights suited to stadiums, sports fields as well as public, commercial and transport facility outdoor applications. Sturdy design coupled with unique light distribution delivers a highly effective solution for large space exterior lighting needs. Suitable for cut-off flood lighting applications.
Product details
- Light output up to 104,000Lm
- Built in surge protection
- Government energy rebates available
Additional options
Other RAL colours, CRI, CCT and beam angles available on request. Additional custom options such as 415V, 2 phase input, Inventronics or Mean Well driver, dimming options and flexible cable (main input) at various lengths (10m,15m, 20m, 30m ,etc.) are also available.
Applications
- Outdoor sports fields
- Roadways
- Airports & sea ports
- Rail yards, ship docks, container terminals, ferry terminals
- Industrial and commercial sites
- Prisons
Accessories
- IP66 junction box
- Asymmetrical louvre
- Cable connector
- Protective metal wire guard (optional)
LED
Illumination grade LED light source.
LED Driver
High-end programmable Mean Well or Inventronics Series remote LED driver, with 10kV surge protection provides excellent performance and lifespan.
Specifications
Stealth Flood 1 G1 series lights are available from 100W to 800W.
| LTT-LHM100N | LTT-LHM200N | LTT-LHM300M | LTT-LHM400M | LTT-LHM500N | LTT-LHM600N | LTT-LHM800N | |
|---|---|---|---|---|---|---|---|
| Nominal Wattage | 100W | 200W | 300W | 400W | 500W | 600W | 800W |
| Item code | 112089 | 110735 | 112090 | 112091 | 110303 | 110304 | 112045 |
| LED qty (pcs) | 200 | 400 | 600 | 800 | 1,000 | 1,200 | 1,600 |
| AC input voltage | 100-277V 50/60Hz | ||||||
| LED brand | NICHIA3030 | ||||||
| Driver brand | Mean Well | ||||||
| Max current @ 115V | 0.97A | 1.93A | 2.548A | 3.396A | 4.32A | 5.043A | 7.73A |
| Max current @ 230V | 0.48A | 0.97A | 1.45A | 1.93A | 2.42A | 2.90A | 3.86A |
| Max current @ 277V | 0.40A | 0.80A | 1.179A | 1.526A | 1.91A | 2.2A | 3.21A |
| Operating temperature | -40°C to +50°C | ||||||
| Power factor (PF) | 0.95 | ||||||
| THD | <20% | ||||||
| Leakage current | Preliminary | ||||||
| Surge protection rating | 10kV (20kV optional) | ||||||
| Lumen output (+/-5%) | 13,000lm | 26,000lm | 39,000lm | 52,000lm | 65,000lm | 78,000lm | 104,000lm |
| Luminaire efficacy (+/-5%) | 130lm/W | ||||||
| Luminaire classification | Class I | ||||||
| Light distribution type | Asymmetrical | ||||||
| CRI | 80 (70 optional) | ||||||
| CCT | 5000K (3000K & 4000K optional) | ||||||
| Rating | IP66 | ||||||
| Impact rating | IK10 | ||||||
| Control system | 0-10V or Dali dim (optional) | ||||||
| Mounting options | U-bracket / Slip fitter | ||||||
| Spigot size | / | ||||||
| Cable gland | / | / | M16*1.5 | M16*1.5 | M16*1.5 | M16*1.5 | M16*1.5 |
| Cable Ø entry range | / | / | 2–2.5mm | 2–2.5mm | 2–2.5mm | 2–2.5mm | 2–2.5mm |
| Body material | Aluminium | ||||||
| Shell colour | Grey | ||||||
| Optics / lens cover | Glass | ||||||
| Lumen maintenance | 50,000 hrs | ||||||
| Driver position | Integral (remote driver optional) | ||||||
| Certifications | TUV RHEINLAND, CE, RoHS, SAA*, RCM, ISO 9001:2015 * SAA applies to LTT-LHM300M, LTT-LHM400M, LTT-LHM500N, LTT-LHM600N, LTT-LHM800N only |
||||||
| Packaging type | 1 unit / carton | ||||||
Dimensions
Detailed dimension drawings and polar diagrams are available from our team. Get in touch to discuss with our lighting experts.
Measurements and illustrations are approximate, do not scale.
| LTT-LHM100N & LTT-LHM200N | LTT-LHM300M & LTT-LHM400M | LTT-LHM500N, LTT-LHM600N & LTT-LHM800N | |
|---|---|---|---|
| Dimensions (mm) | 642 x 260 x 152 | 682 x 466 x 152 | 710 x 715 x 170 |
| Weight with driver | 10.85kg | 20kg | 32.4kg (33.8kg for 800W) |
Beam Angles
Average beam angle (50%):
71.2°
–
–
–
