Stealth Flood 4

High output, illumination grade LED flood lights suited to high pole and large scale outdoor lighting

Illumination grade LED flood lights with high-end programmable LED drivers. Suitable for large space exterior lighting needs such as high pole square lighting, large outdoor stadiums and sports fields, harbour, wharfs, tower cranes and open air markets. Variety of beam angles plus custom options available on request.

Product details

  • Illumination grade LUMILEDS® LUXEON 3030 LEDs – excellent lumen output up to 180,000lm
  • High end programmable Mean Well or Inventronics Series LED driver with integral dimming function
  • Built in 4kV surge protection
  • Multiple beam angles available
  • Government energy rebates available

Additional options

Other RAL colours, CRI, CCT and beam angles available on request. Additional custom options such as 415V and 2 phase input are also available.

Applications

  • High Pole square lighting
  • Stadium & large outdoor stadium lighting
  • Harbour & wharfs
  • Tower cranes
  • Open air markets

CERoHS compliantRCM TickISO9001IP66

LED

Illumination grade LED light source.

LumiledsNichiaOsram


LED Driver

High-end programmable  Mean Well or Inventronics Series LED driver, with integrall dimming function and 4kV surge protection, provides excellent performance and lifespan.

InventronicsMean Well

Specifications

LYQCD-500W LYQCD-1000W LYQCD-1500W
Item code (for 25°) 112097 112098 111080
Nominal Wattage 500W 1000W 1500W
LED qty (pcs) 560 1,120 1,680
AC input voltage 90-305V 50/60Hz
LED brand Lumileds 3030
Driver brand Mean Well
Max current @115V 4.1A 8.3A 12.4A
Max current @230V 2.1A 4.1A 6.2A
Max current @277V 1.7A 3.4A 5.1A
Operating temperature -40°C to +50°C
Power factor (PF) >0.95
THD <20%
Leakage current ≤5mA
Surge protection 10kV (20kV optional)
Lumen output (+/-5%) 65,000lm 127,000lm 192,000lm
Luminaire efficacy (+/-5%) 120lm/W
Luminaire classification Class I
Light distribution type Symmetrical
Beam angle  25° 45° 60° (10° 90°  optional)
Ra >80
CCT 5000K (3000K, 4000K, 5700K optional)
Rating IP66
Impact rating IK08
Mounting options Bracket installation / Hanging ring installation / Hanging rod installation
Spigot size /
Cable gland PG11
Cable Ø entry range 5-10mm
Body material Aluminium alloy
Shell colour Black or other RAL colours available on request
Optics / lens cover Polycarbonate
Lumen maintenance >60,000 hours-L₇₀ at 25°C
Certifications CE, RoHS, RCM, ISO 9001:2015
Packaging type 1 unit / carton

Dimensions

Detailed dimension drawings and polar diagrams are available from our team. Get in touch to discuss with our lighting experts.
Measurements and illustrations are approximate, do not scale.

LYQCD-500W LYQCD-1000W LYQCD-1500W
Dimensions (mm) 325 x 472 x 160 629 x 536 x 160 890 x 536 x 160
Weight 15kg 25.8kg 36.6kg
Stealth Flood 4 LYQCD 500W
LYQCD-500W
Stealth Flood 4 LYQCD 1000W
LYQCD-1000W
Stealth Flood 4 LYQCD 1500W
LYQCD-1500W

Beam Angles

Average beam angle (50%): 10°, 25°,45°,60° & 90° (optional).

Beam angle 10 degree
10°

Beam angle 25 degree
25°

Beam angle 45 degree
45°

Beam angle 60 degree
60°

Beam angle 90 degree
90°
