Stealth Flood 3

Illumination grade LED flood lights with multiple beam angles and light distribution types

Robust, long lasting, highly efficient flood lights. suited to stadiums, sports fields, shopping centres, parking lots and. Robust design coupled with unique light distribution delivers a highly effective solution for large space exterior lighting needs.

Product details

  • Illumination grade REFOND SMD LEDs – excellent lumen output up to 37,500lm
  • High end programmable Sosen or Done LED driver
  • Built in 12kV surge protection
  • Multiple beam angles and light distribution types available
  • Government energy rebates available
  • 5 year warranty

Additional options

Other RAL colours, CRI, CCT, beam angle, and light distribution type available on request with a variety of optional accessories.

Applications

  • Tennis courts
  • Basketball courts
  • Exhibition centres
  • Shopping centres
  • Stadiums
  • Accent lighting
  • Parking lots



LED

Illumination grade LED light source.

Refond


LED Driver

High-end programmable Sosen or Done LED driver,  with 12KV surge protection provides excellent performance and lifespan.

DoneSoren

Specifications

LGL11-100-120 LGL11-150-120 LGL11-200-120 LGL11-300-120
Item code 112095 112049 112050 112096
Nominal Wattage 100W 150W 200W 300W
LED qty (pcs) 128 192 240 384
Input voltage 220-270V AC 50/60Hz
LED brand REFOND
Driver brand Done or Sosen
Max current @115V 0.87A 1.3A 1.74A 2.6A
Max current @230V 0.457A 0.687A 0.937A 1.4A
Max current @277V 0.365A 0.554A 0.746A 1.128A
Operating temperature -30°C to +50°C
Power factor (PF) >0.93
THD <10%
Leakage current ≤0.7mA pk
Surge protection 12kV
Lumen output (+/-5%) 12,600lm 18,200lm 24,200lm 36,700lm
Luminaire efficacy (+/-5%) 125lm/W
Luminaire classification Class I
Light distribution type Symmetrical (asymmetrical optional)
Beam angle 120° (15° 30° 60° 90° F01601 & F01602 optional)
CRI 80 (70 optional)
CCT 5000K (3000K, 4000K optional)
Rating IP66
Impact rating IK08
Mounting options Bracket or pole mounting
Spigot size Ø42, Ø60, Ø72
Cable gland M16
Cable Ø entry range 3*1.0mm²
Body material Aluminium alloy
Shell colour Black
Optics / lens cover Tempered glass and polycarbonate
Lumen maintenance >50,000 hours-L₇₀ at 30°C
Certifications SAA, RCM, ISO 9001:2015
Packaging type 1 unit / carton

Dimensions

Detailed dimension drawings and polar diagrams are available from our team. Get in touch to discuss with our lighting experts.
Measurements and illustrations are approximate, do not scale.

LGL11-100-120 LGL11-150-120 LGL11-200-120 LGL11-300-120
Dimensions (mm) 335 x 295 x 71 375 x 320 x 75 400 x 345 x 78 455 x 410 x 83
Weight 3.4kg 4.5kg 5.5kg 8.3kg

LGL11-100-120 Dimension Drawing
LGL11-100-120
LGL11-150-120 Dimension Drawing
LGL11-150-120
LGL11-200-120 Dimension Drawing
LGL11-200-120
LGL11-300-120 Dimension Drawing
LGL11-300-120 Dimension Drawing

Beam Angles

Average beam angle (50%): 120º (15° 30° 60° 90° F01601 & F01602 optional).

Beam angle 120º120º

Beam angle 15º15º

Beam angle 30º
30º

Beam angle 60º
60º

Beam angle 90º
90º

Beam angle F01601
F01601

Beam angle F01602
F01602
